Product Specification:
12V Deep Cycle Lithium Batteries Manufacturers
LiFePO4 Batteries for Any Application
Luwin Energy have more than 20 years’ experience in lithium batteries designing and manufacturing, LiFePO4 battery is now very popular to use in RV, Marine, Golf cart, Solar due to high density. 12V lithium batteries are of more than 2000 cycle life with BMS built-in. Our batteries are with IEC/CE/ROHS/UN38.3/MSDS certificates. LiFePO4 Batteries are for Any Application
12v 100ah Lithium Ion Battery
Chief Datasheet
Model: LW-LFP1260-A | |
Nominal Voltage | 12.8V |
Nominal Capacity | 60Ah |
Energy | 768Wh |
Efficiency | ≥98% |
Cycle life | ＞3000 cycles @80% DOD |
Dimension(L*W*H) | Customized |
Terminal Type | M6 or M8 screw |
Case Material | Metal |
Enclosure protection | IP66 |
Key Features
● Light, powerful, and offering a very long viewing time, this Lithium-ion battery is particularly suitable for cyclic use, when batteries are frequently charged and discharged.
● Built-in BMS. 100% of the capacity is available for your needs, without voltage drop!
● Lithium batteries (Lithium Iron Phosphate) offer many advantages over lead batteries.
● They have a much faster-charging capacity, which allows you to use even the smallest amount of sunlight without being limited by the internal resistance of the battery.
● A lead battery, depending on its capacity will be limited in charging power.
● With lithium, you will charge with the maximum of what the controller can give.
● Unbeatable also when discharging, they easily withstand very fast discharges.
● Comparing the price per ampere-hour available (with lithium you have a very high depth of discharge) we can see that the price per Ah available is just a little bit more expensive than lead batteries.
● Lithium batteries have many advantages.
● High number of charge/discharge cycles :
● Service life at 80% depth of discharge (DoD) >/= 3000
● Service life at 50% depth of discharge (DoD) LiFePO4 battery >/= 4500
Details Specifications:
Model: LW-LFP1260-A | |
Electrical Specification | |
Nominal Voltage | 12.8V |
Nominal Capacity | 60Ah |
Capacity @30A | 2HR |
Energy | 768Wh |
Resistance | ≤10mΩ |
Efficiency | ≥98% |
Self Discharge | ＜3% per month |
Cycle life | ＞3000 cycles @80% DOD |
Charge specification | |
Standard charge | Constant current 20A. Constant voltage 14.6V, to charge current 1A cut-off @25±2℃. |
Standard charge time | Approx. 4h |
Max. Charge current | 60A |
Charge Voltage cut-off | 14.6V (1±0.2S) |
Charge temperature | -20～55℃ |
Discharge specification | |
Max. Constant discharge | 60A |
Peak discharge current | 120A (30S) |
Max. peak discharge current | no less than 200 (5s) |
Discharge voltage cut-off | 11.2V |
BMS discharge cut-off | 10V |
Short circuit protection | 200-600μs |
Discharge temperature | -30～55℃ |
Mechanical Specifications | |
Dimension(L*W*H) | 170*160*160mm |
Weight | 9.8±0.2kg |
Terminal Type | M6 or M8 screw |
Case Material | Metal |
Enclosure protection | IP66 |
Combination method | 4S1P |
Total cells | 4 pieces |
Main Export Markets:
Asia/Australasia Central/South America/Eastern Europe/Mid East/Africa North America/Western Europe
Whether you are ready to order or just want a price quote we will do our best to assist you. Please fill in the form below with your contact info, or send your inquiry to inquiry@luwinenergy.com, we will get back to you as soon as possible.
